Parameters

:

pH, mV and Temperature

Display

:

16 x 2 lines Alphanumeric LCD display with backlit

Key Board

:

6 keys, soft touch membrane type

Power supply

:

230V 10% AC, 50 Hz.

Setting

:

By Soft Touch Keys

Interface

:

Serial RS-232 Port

Range

:

0.00 to 14.00 pH

Resolution

:

0.01 pH

Relative Stability

:

0.02 pH/Hour

Accuracy

:

0.02 pH 1 digit

Temperature Compensation

:

0 to 100C Auto/Manual

Automatic with Temp. Probe & Manual by Keys

Auto Buffer Recognition

:

4.00, 7.00 & 9.20

Acceptable Electrode Slope

:

70% to 130%

Calibration

:

Auto / Manual (2-POINT/3-POINT)

Range

:

0 to + 1999.9 mV

Resolution

:

0.1 mV & 0.01 mV

Accuracy

:

0.1 mV 1 Digit

Calibration

:

MANUAL

Range

:

0.00 TO 100.00 C

Resolution

:

0.1 C

Accuracy

:

0.1 C

Input Type

:

Semi-Conductor Type

Calibration

:

Auto/Manual

1.

Combination pH Electrode

1 No.

2.

Temperature Probe

1 No.

3.

Dust Cover

1 No.

4.

Instruction Manual

1 No.

5.

Electrode stand

1 No.

6.

Buffer Capsules

(4.00, 7.00, 9.20 pH)

1 No.
